| Medium | water with glycol <50% |
| description of thermostatic valve connection | threaded connection M30 x 1.5 |
| thermostatic valve nominal diameter | nominal size 15 |
| kvs value | 3.0 m³/h |
| Max. operating temperature | 90 °C |
| Max. operating pressure | PN 16 |
| Pipework | corrugated stainless steel tubes |
| Connection | R1/2 inch external thread, Cu-DN12 |
| Number of pipes | 4 pieces |
| Pipe length | 600 mm |
| length of insulation hose | 500 mm |
