| Medium | water with glycol <50% |
| description of thermostatic valve connection | connection: Rp 3/4 inch female x R 3/4 inch male |
| thermostatic valve nominal diameter | nominal size 20 |
| kvs value | 3.6 m³/h |
| Max. operating temperature | 90 °C |
| Max. operating pressure | PN 10 |
| Max. differential pressure | 5 bar |
| Pipework | including adapted length compensation nipple |
