Intelligent single-room control
The new pioneering technology for the integration of Kampmann products into buildings.
Your vision of smart room control – now a reality
More comfort, maximum efficiency and complete control: our innovative climate control system KaControl MC opens up new possibilities for the control and networking of Kampmann products with building automation systems.
Configurable room control unit
Its compact 2-inch colour display with touchscreen permits intuitive control using familiar typing and swiping gestures. The controller is tailored exactly to your needs, thanks to the integrated temperature sensor and individually adjustable menus.
Compatibility with numerous switch programs and three selectable display background colors open up new opportunities for visual integration into rooms.
Plug & Play installation thanks to Webserver
Each unit is equipped with an integrated Webserver, which provides for convenient parametrization and operation in addition to the room control unit. A guided quick configuration menu ensures effortless commissioning. Configure the unit flexibly on a laptop, smartphone or directly on the room control unit – using Wi-Fi or by network cable.
You will also obtain visualization of live data in operation and an overview of up to four weeks of trend data.
CAN bus technology
Operate up to ten units in each group* and benefit from:
Permanent data communication between all units in a group
Cable lengths of up to 100 metres
Fault and communication monitoring for maximum operational safety
Automatic addressing of all CAN bus subscribers
Maximum flexibility in the room
Multifunctional inputs
Five flexibly configurable inputs on each unit can be flexibly used for the entire group:
Window contacts, presence detectors
Room, supply air, air intake, supply temperature, return temperature ...
Outputs
There are two different control configurations KaControl MC1 and KaControl MC2 for secondary air units
| Control configuration | KaControl MC1 | KaControl MC2 |
|---|---|---|
| Article number ending | *M1 | *M2 |
| Technical difference | Continuous fan control and Open/Closed valve control | Continuous fan control and continuous valve actuation |
| Functions | Maximum efficiency room temperature control |
Additional:
|
| Available from | Immediately | Gradually per product group |
Connectivity by license
Seamless integration into your building automation system: all popular interfaces are always available as standard with Modbus RTU, Modbus TCP, BACnet IP and KNX. The required communication protocol can be activated as a license for each unit during production or afterwards – for maximum flexibility during the project.
Has the design of your control system not yet been finalized? That is irrelevant, as controls can be integrated into all scenarios independently of the choice of Kampmann unit. Unit selection continues to be unaffected even in the event of changes to the control system design.
Raumbediengerät
Touch Panel TP 2
- Hochauflösendes Full-Touch-Farbdisplay mit drei wählbaren Displayfarben
- Intuitive Menüführung und Bedienung mittels bekannter Tipp- und Wischgesten
- Passend für alle gängigen Schalterprogramme (55 x 55 mm)
- Zur Bedienung, Parametrierung und Überwachung
