Basic unit
Kampmann KaCool D HY hygienic ceiling fan coil cassette for the air conditioning of rooms with suspended ceilings and exacting hygiene requirements. Hygiene-compliant according to VDI 6022 (Hygiene requirements governing ventilation systems and units) through the HYBETA hygiene institute.
Basic unit made of sendzimir galvanised sheet steel, partially insulated with a vapour diffusion and noise-reducing layer to prevent the ingress of condensation. A two-section aesthetic metal panel in RAL 9016 (traffic white) consisting of a lower frame and a visible panel is supplied separately. With a folding panel for cleaning and maintenance. Filter ePM1>50% (F7)
Heat exchanger
High-output heat exchanger, consisting of round copper tubes with aluminium fins, suitable for use with LPHW. Venting screws on the connection provide for simple and clean venting during commissioning.
| System | | 4-pipe |
| Max. operating pressure | bar | 8 |
| Max. entering water temperature | °C | 75 |
| Min. entering water temperature | °C | 6 |
| Max. air inlet temp. | °C | 35 |
| Max. glycol volume | % | 50 |
Condensate tray
Stainless steel built-in condensate tray with a gradient on all sides with a free outlet for the complete discharge of condensate. Condensate tray designed as an independent component that can be removed for cleaning and maintenance in accordance with VDI 6022.
Fan
Energy-saving EC fan with 0-10 V input for continuously variable speed control. All rotating parts have low-noise and maintenance-free bearings. Factory-wired.
Control
- electromechanically wired to terminal.
Configuration
| Model size | | 3 |
| Filter class | | Filter ePM1>50% (F7) |
| Width (body) | mm | 575 |
| Length (body) | mm | 575 |
| Height (body) | mm | 385 |
| Width (Casing panels) | mm | 600 |
| Length (panel) | mm | 600 |
| Height (aperture) | mm | 42 |
| Weight | kg | 36.5 |
| output voltage | V | 230 |
| frequency | Hz | 50 |
| Connection | | |
| | female thread |
